Sundance::MeshSourceBase Class Reference
Public Member Functions | |
| MeshSourceBase (const MeshType &meshType, int verbosity, const MPIComm &comm) | |
| MeshSourceBase (const ParameterList ¶ms) | |
| virtual | ~MeshSourceBase () |
| Mesh | getMesh () const |
Extraction of attributes | |
| void | getAttributes (RCP< Array< Array< double > > > &nodeAttributes, RCP< Array< Array< double > > > &elemAttributes) const |
Printable interface | |
| virtual void | print (std::ostream &os) const |
Describable interface | |
| virtual std::string | description () const |
| const MPIComm & | comm () const |
Protected Member Functions | |
| int | myRank () const |
| int | nProc () const |
| virtual Mesh | fillMesh () const =0 |
| Mesh | createMesh (int dim) const |
| RCP< Array< Array< double > > > & | nodeAttributes () const |
| RCP< Array< Array< double > > > & | elemAttributes () const |
Private Attributes | |
| Mesh | cachedMesh_ |
| bool | hasCachedMesh_ |
| MeshType | meshType_ |
| MPIComm | comm_ |
| RCP< Array< Array< double > > > | elemAttributes_ |
| RCP< Array< Array< double > > > | nodeAttributes_ |
Detailed Description
MeshSourceBase provides the internal interface for mesh sources, i.e., objects such as mesh generators and file readers that can produce a mesh object. The action of a mesh source should be independent of the internal mesh representation used. To allow user-level specification of the type of internal mesh representation to be used, a MeshSourceBase is constructed with a MeshType object which acts as a factory to produce empty meshes.Mesh sources are constructed with a MPI communicator. If the communicator has more than one processor, the mesh created will be distributed.
Writing your own MeshSourceBase subtype
The only method you will need to override is
-
virtual Mesh fillMesh() const
See the PartitionedLineMesher source code for a very simple example of how to write a mesh source subtype.
Optionally, you can override the description() method to provide more informative descriptive output than the std::string "MeshSourceBase[unknown subtype]".
Definition at line 79 of file SundanceMeshSourceBase.hpp.
Constructor & Destructor Documentation
Construct with a mesh type and MPI communicator
Definition at line 13 of file SundanceMeshSourceBase.cpp.
| MeshSourceBase::MeshSourceBase | ( | const ParameterList & | params | ) |
Construct from a parameter list
Definition at line 26 of file SundanceMeshSourceBase.cpp.
| virtual Sundance::MeshSourceBase::~MeshSourceBase | ( | ) | [inline, virtual] |
virtual dtor
Definition at line 95 of file SundanceMeshSourceBase.hpp.
Member Function Documentation
| const MPIComm& Sundance::MeshSourceBase::comm | ( | ) | const [inline] |
access to the MPI communicator
Definition at line 122 of file SundanceMeshSourceBase.hpp.
References comm_.
Referenced by Sundance::PartitionedLineMesher::fillMesh(), myRank(), nProc(), and Sundance::PartitionedRectangleMesher::PartitionedRectangleMesher().
| Mesh MeshSourceBase::createMesh | ( | int | dim | ) | const [protected] |
createMesh() physically allocates the mesh object
Definition at line 64 of file SundanceMeshSourceBase.cpp.
References cachedMesh_, comm_, Sundance::MeshType::createEmptyMesh(), hasCachedMesh_, meshType_, Playa::Handle< PointerType >::ptr(), and Playa::ObjectWithVerbosity::verb().
Referenced by Sundance::PeanoMesher3D::fillMesh(), Sundance::PeanoMesher2D::fillMesh(), Sundance::PartitionedRectangleMesher::fillMesh(), Sundance::PartitionedLineMesher::fillMesh(), Sundance::OneTetMesher::fillMesh(), Sundance::OneTriangleMesher::fillMesh(), Sundance::HNMesher3D::fillMesh(), Sundance::HNMesher2D::fillMesh(), Sundance::ExodusNetCDFMeshReader::fillMesh(), Sundance::ExodusMeshReader::fillMesh(), Sundance::BamgMeshReader::readMesh(), and Sundance::TriangleMeshReader::readNodes().
| virtual std::string Sundance::MeshSourceBase::description | ( | ) | const [inline, virtual] |
Print to a stream
Reimplemented in Sundance::BamgMeshReader, Sundance::ExodusMeshReader, Sundance::ExodusNetCDFMeshReader, Sundance::HNMesher2D, Sundance::HNMesher3D, Sundance::OneTriangleMesher, Sundance::OneTetMesher, Sundance::PartitionedLineMesher, Sundance::PartitionedRectangleMesher, Sundance::PeanoMesher2D, Sundance::PeanoMesher3D, Sundance::PeriodicLineMesher, and Sundance::TriangleMeshReader.
Definition at line 118 of file SundanceMeshSourceBase.hpp.
Referenced by print().
| RCP<Array<Array<double> > >& Sundance::MeshSourceBase::elemAttributes | ( | ) | const [inline, protected] |
internal access to the element attributes
Definition at line 147 of file SundanceMeshSourceBase.hpp.
References elemAttributes_.
Referenced by Sundance::ExodusMeshReader::fillMesh(), Sundance::TriangleMeshReader::readElems(), and Sundance::BamgMeshReader::readMesh().
| virtual Mesh Sundance::MeshSourceBase::fillMesh | ( | ) | const [protected, pure virtual] |
Fill a mesh object with data from the source. Subclass implementors will need to provide a fillMesh() for their subclass. Implementors should use the createMesh() method for the allocation of the new mesh.
Implemented in Sundance::BamgMeshReader, Sundance::ExodusMeshReader, Sundance::ExodusNetCDFMeshReader, Sundance::HNMesher2D, Sundance::HNMesher3D, Sundance::OneTriangleMesher, Sundance::OneTetMesher, Sundance::PartitionedLineMesher, Sundance::PartitionedRectangleMesher, Sundance::PeanoMesher2D, Sundance::PeanoMesher3D, Sundance::PeriodicLineMesher, and Sundance::TriangleMeshReader.
Referenced by getMesh().
| void MeshSourceBase::getAttributes | ( | RCP< Array< Array< double > > > & | nodeAttributes, | |
| RCP< Array< Array< double > > > & | elemAttributes | |||
| ) | const |
Definition at line 57 of file SundanceMeshSourceBase.cpp.
| Mesh MeshSourceBase::getMesh | ( | ) | const |
Get a mesh from the source. If a mesh has already been created, this method will return the cached mesh, otherwise it will build on with a call to fillMesh()
Definition at line 37 of file SundanceMeshSourceBase.cpp.
References cachedMesh_, fillMesh(), hasCachedMesh_, Sundance::Mesh::numCells(), Sundance::Mesh::spatialDim(), and Playa::ObjectWithVerbosity::verb().
| int Sundance::MeshSourceBase::myRank | ( | ) | const [inline, protected] |
Get processor rank
Definition at line 129 of file SundanceMeshSourceBase.hpp.
References comm(), and Playa::MPIComm::getRank().
Referenced by Sundance::BamgMeshReader::BamgMeshReader(), Sundance::ExodusMeshReader::ExodusMeshReader(), Sundance::PartitionedRectangleMesher::fillMesh(), Sundance::PartitionedLineMesher::fillMesh(), Sundance::TriangleMeshReader::readParallelInfo(), Sundance::ExodusMeshReader::readParallelInfo(), Sundance::BamgMeshReader::readParallelInfo(), and Sundance::TriangleMeshReader::TriangleMeshReader().
| RCP<Array<Array<double> > >& Sundance::MeshSourceBase::nodeAttributes | ( | ) | const [inline, protected] |
internal access to the node attributes
Definition at line 143 of file SundanceMeshSourceBase.hpp.
References nodeAttributes_.
Referenced by Sundance::ExodusMeshReader::fillMesh(), Sundance::BamgMeshReader::readMesh(), and Sundance::TriangleMeshReader::readNodes().
| int Sundance::MeshSourceBase::nProc | ( | ) | const [inline, protected] |
Get number of processors
Definition at line 131 of file SundanceMeshSourceBase.hpp.
References comm(), and Playa::MPIComm::getNProc().
Referenced by Sundance::BamgMeshReader::BamgMeshReader(), Sundance::ExodusMeshReader::ExodusMeshReader(), Sundance::ExodusNetCDFMeshReader::ExodusNetCDFMeshReader(), Sundance::PartitionedRectangleMesher::fillMesh(), Sundance::PartitionedLineMesher::fillMesh(), Sundance::ExodusMeshReader::fillMesh(), Sundance::TriangleMeshReader::readElems(), Sundance::TriangleMeshReader::readNodes(), Sundance::TriangleMeshReader::readParallelInfo(), Sundance::ExodusMeshReader::readParallelInfo(), Sundance::BamgMeshReader::readParallelInfo(), and Sundance::TriangleMeshReader::TriangleMeshReader().
| virtual void Sundance::MeshSourceBase::print | ( | std::ostream & | os | ) | const [inline, virtual] |
Print to a stream
Implements Playa::Printable.
Definition at line 112 of file SundanceMeshSourceBase.hpp.
References description().
Member Data Documentation
Mesh Sundance::MeshSourceBase::cachedMesh_ [mutable, private] |
Definition at line 155 of file SundanceMeshSourceBase.hpp.
Referenced by createMesh(), and getMesh().
MPIComm Sundance::MeshSourceBase::comm_ [private] |
RCP<Array<Array<double> > > Sundance::MeshSourceBase::elemAttributes_ [mutable, private] |
bool Sundance::MeshSourceBase::hasCachedMesh_ [mutable, private] |
Definition at line 158 of file SundanceMeshSourceBase.hpp.
Referenced by createMesh(), and getMesh().
MeshType Sundance::MeshSourceBase::meshType_ [private] |
RCP<Array<Array<double> > > Sundance::MeshSourceBase::nodeAttributes_ [mutable, private] |
