Public Member Functions | |
HNDoFMapBase (const Mesh &mesh, int nFuncs, int setupVerb) | |
virtual | ~HNDoFMapBase () |
virtual void | getTrafoMatrixForCell (int cellLID, int funcID, int &trafoMatrixSize, bool &doTransform, Array< double > &transfMatrix) const =0 |
virtual void | getTrafoMatrixForFacet (int cellDim, int cellLID, int facetIndex, int funcID, int &trafoMatrixSize, bool &doTransform, Array< double > &transfMatrix) const =0 |
virtual void | getDOFsForHNCell (int cellDim, int cellLID, int funcID, Array< int > &dofs, Array< double > &coefs) const =0 |
int | getSpacialMeshDim () const |
Private Attributes | |
const Mesh | mesh_ |
Definition at line 24 of file SundanceHNDoFMapBase.hpp.
Sundance::HNDoFMapBase::HNDoFMapBase | ( | const Mesh & | mesh, | |
int | nFuncs, | |||
int | setupVerb | |||
) | [inline] |
Empty Ctor
Definition at line 29 of file SundanceHNDoFMapBase.hpp.
virtual Sundance::HNDoFMapBase::~HNDoFMapBase | ( | ) | [inline, virtual] |
Definition at line 31 of file SundanceHNDoFMapBase.hpp.
virtual void Sundance::HNDoFMapBase::getDOFsForHNCell | ( | int | cellDim, | |
int | cellLID, | |||
int | funcID, | |||
Array< int > & | dofs, | |||
Array< double > & | coefs | |||
) | const [pure virtual] |
Function used for plotting for hanging node DOFMaps Returns for one hanging node (element) the global DoFs which contribute to that hanging local DoF
cellDim | [in] the dimension | |
cellLID | [in] the LID of the cell | |
funcID | [in] the function ID, (to wchich the DOFs belong) | |
dofs | [out] the global DoF s | |
coefs | [out] the coefficient of each global DoF |
Implemented in Sundance::InhomogeneousDOFMapHN, Sundance::MixedDOFMapHN, and Sundance::NodalDOFMapHN.
Referenced by Sundance::ExprFieldWrapper::getData().
int Sundance::HNDoFMapBase::getSpacialMeshDim | ( | ) | const [inline] |
Returns the dimension where the DoF map is defined For HN we do transformation only for the maxCell type
Definition at line 81 of file SundanceHNDoFMapBase.hpp.
References mesh_, and Sundance::Mesh::spatialDim().
virtual void Sundance::HNDoFMapBase::getTrafoMatrixForCell | ( | int | cellLID, | |
int | funcID, | |||
int & | trafoMatrixSize, | |||
bool & | doTransform, | |||
Array< double > & | transfMatrix | |||
) | const [pure virtual] |
cellLID | [in] the maxCell LID input | |
funcID | [in] the function ID | |
trafoMatrixSize | [in/out] | |
doTransform | [out] | |
transfMatrix | [out] (we assume that the array is already pre-sized ) |
Implemented in Sundance::InhomogeneousDOFMapHN, Sundance::MixedDOFMapHN, and Sundance::NodalDOFMapHN.
virtual void Sundance::HNDoFMapBase::getTrafoMatrixForFacet | ( | int | cellDim, | |
int | cellLID, | |||
int | facetIndex, | |||
int | funcID, | |||
int & | trafoMatrixSize, | |||
bool & | doTransform, | |||
Array< double > & | transfMatrix | |||
) | const [pure virtual] |
Function to apply transformation for facets
cellDim,the | facet dimension | |
cellLID,facet | LID | |
facetIndex,facet | index in the maxCofacet | |
funcID | [in] the function ID | |
trafoMatrixSize | [in/out] | |
doTransform | [out] | |
transfMatrix | [out] (we assume that the array is already pre-sized ) |
Implemented in Sundance::InhomogeneousDOFMapHN, Sundance::MixedDOFMapHN, and Sundance::NodalDOFMapHN.
const Mesh Sundance::HNDoFMapBase::mesh_ [private] |
