Public Member Functions | |
DOFMapBase (const Mesh &mesh, int setupVerb) | |
| |
virtual | ~DOFMapBase () |
| |
const Mesh & | mesh () const |
| |
bool | isRemote (int cellDim, int cellLID, int &ownerProcID) const |
Return true if the given cell is really owned by another process and is only ghosted in this process (and optionally return the owning process ID). | |
virtual void | getDOFsForCell (int cellDim, int cellLID, int funcID, Array< int > &dofs) const |
Get the global DOFs for a single function on a single cell. | |
virtual RCP< const MapStructure > | getDOFsForCellBatch (int cellDim, const Array< int > &cellLIDs, const Set< int > &requestedFuncSet, Array< Array< int > > &dofs, Array< int > &nNodes, int verb) const =0 |
Return the global DOFs for a batch of cells for a given set of functions on those cells. | |
virtual RCP< const Set< int > > | allowedFuncsOnCellBatch (int cellDim, const Array< int > &cellLIDs) const =0 |
Return the set of a function IDs for a batch of cells for which DOFs can be obtained. | |
virtual const Array< CellFilter > & | funcDomains () const =0 |
Return an array of cell filters that gives, for each function ID, the cells that the function lives on. | |
int | lowestLocalDOF () const |
Return the lowest DOF for DOFs owned in this process. | |
bool | isLocalDOF (int dof) const |
Returns true if the given global DOF is owned in this process. | |
int | numLocalDOFs () const |
Return the number of DOFs owned in this process. | |
int | numDOFs () const |
Return the global number of DOFs over all processes. | |
const RCP< Array< int > > & | ghostIndices () const |
Return an array of the global DOFs for the DOFs that are locally accessed in this process. | |
virtual void | print (std::ostream &os) const =0 |
Print the DOF map. | |
virtual bool | isHomogeneous () const |
Returns true if the map is homogeneous. | |
virtual int | cellDim () const |
The largest dimension cell supported by this DOF map. Usually, this will be the spatial dimension of the mesh. However, for functions defined only on a surface, curve, or point set it may be lower. Such maps should override the default. | |
int | setupVerb () const |
Protected Member Functions | |
void | setLowestLocalDOF (int low) |
void | setNumLocalDOFs (int numDOFs) |
void | setTotalNumDOFs (int numDOFs) |
const MPIComm & | comm () const |
void | addGhostIndex (int dof) |
Static Protected Member Functions | |
static Teuchos::Time & | dofLookupTimer () |
static Teuchos::Time & | batchedDofLookupTimer () |
Private Attributes | |
int | setupVerb_ |
int | localProcID_ |
Mesh | mesh_ |
int | lowestLocalDOF_ |
int | numLocalDOFs_ |
int | numDOFs_ |
RCP< Array< int > > | ghostIndices_ |
A degree of freedom (DOF) map is a parallel-aware object that takes takes DOFs on individual cells in the whole mesh, and creates global IDs for them on the whole mesh across processes.
A DOF map is constructed out of a mesh and assignment of various discrete functions with various basis-es assigned to the different cells in the mesh;
This interface assumes that the global DOFs owned in this process are ordered sequentially so the DOFs owned in this process are given by this->lowestLocalDOF() + k
, for k = 0...this->numLocalDOFs()-1()
, where this->numLocalDOFs()
is the number of DOFs owned by this process. Therefore, any DOF with value less than this->numLocalDOFs()
and greater than or equal to this->lowestLocalDOF()+this->numLocalDOFs()
are necessarily ghosted DOFs. ??? ToDo: I don't think the above is correct! ???
ToDo: Finish documentation!
DOFMapDefaultBase
) and then make this interface a true abstract interface? There are lots of advantages to having pure interface classes (e.g. less documenation, standard delegation subclasses etc.).
MeshBase
object? Is there any reason not to give the client access to the MeshBase
object? If you do this, then you can remove the isRemote()
function and let the client just query the map object directly.
this->numTotalFunctions()
would be very helpful in this regard.
Definition at line 111 of file SundanceDOFMapBase.hpp.
DOFMapBase::DOFMapBase | ( | const Mesh & | mesh, | |
int | setupVerb | |||
) |
virtual Sundance::DOFMapBase::~DOFMapBase | ( | ) | [inline, virtual] |
ToDo: Remove this virtual destructor since this interface already inherits from a base interface that has a virtual destructor.
Definition at line 123 of file SundanceDOFMapBase.hpp.
void Sundance::DOFMapBase::addGhostIndex | ( | int | dof | ) | [inline, protected] |
Definition at line 341 of file SundanceDOFMapBase.hpp.
References ghostIndices_.
Referenced by Sundance::MixedDOFMapHN::setDOFs(), Sundance::MixedDOFMap::setDOFs(), Sundance::InhomogeneousDOFMapHN::setDOFs(), Sundance::HomogeneousDOFMap::setDOFs(), Sundance::SubmaximalNodalDOFMap::shareRemoteDOFs(), Sundance::PartialElementDOFMap::shareRemoteDOFs(), Sundance::NodalDOFMapHN::shareRemoteDOFs(), and Sundance::NodalDOFMap::shareRemoteDOFs().
virtual RCP<const Set<int> > Sundance::DOFMapBase::allowedFuncsOnCellBatch | ( | int | cellDim, | |
const Array< int > & | cellLIDs | |||
) | const [pure virtual] |
Return the set of a function IDs for a batch of cells for which DOFs can be obtained.
cellDim | [in] The dimension of the cells in the batch of cells | |
cellLIDs | [in] Local IDs (LIDs) for the batch of cells |
Implemented in Sundance::InhomogeneousDOFMapHN, Sundance::InhomogeneousEdgeLocalizedDOFMap, Sundance::InhomogeneousNodalDOFMap, Sundance::PartialElementDOFMap, Sundance::SpatiallyHomogeneousDOFMapBase, and Sundance::SubmaximalNodalDOFMap.
Time & DOFMapBase::batchedDofLookupTimer | ( | ) | [static, protected] |
Definition at line 86 of file SundanceDOFMapBase.cpp.
Referenced by Sundance::SubmaximalNodalDOFMap::getDOFsForCellBatch(), Sundance::PartialElementDOFMap::getDOFsForCellBatch(), Sundance::NodalDOFMapHN::getDOFsForCellBatch(), Sundance::NodalDOFMap::getDOFsForCellBatch(), and Sundance::InhomogeneousNodalDOFMap::getDOFsForCellBatch().
virtual int Sundance::DOFMapBase::cellDim | ( | ) | const [inline, virtual] |
The largest dimension cell supported by this DOF map. Usually, this will be the spatial dimension of the mesh. However, for functions defined only on a surface, curve, or point set it may be lower. Such maps should override the default.
Reimplemented in Sundance::SubmaximalNodalDOFMap.
Definition at line 327 of file SundanceDOFMapBase.hpp.
References mesh_, and Sundance::Mesh::spatialDim().
Referenced by Sundance::MixedDOFMapHN::buildMaximalDofTable(), Sundance::MixedDOFMap::buildMaximalDofTable(), Sundance::InhomogeneousDOFMapHN::buildMaximalDofTable(), Sundance::InhomogeneousEdgeLocalizedDOFMap::getEdgeLIDs(), Sundance::PartialElementDOFMap::init(), and Sundance::PartialElementDOFMap::shareRemoteDOFs().
const MPIComm& Sundance::DOFMapBase::comm | ( | ) | const [inline, protected] |
Definition at line 339 of file SundanceDOFMapBase.hpp.
References Sundance::Mesh::comm(), and mesh().
Referenced by Sundance::MixedDOFMapHN::checkTable(), Sundance::MixedDOFMap::checkTable(), Sundance::SubmaximalNodalDOFMap::computeOffsets(), Sundance::PartialElementDOFMap::computeOffsets(), Sundance::NodalDOFMapHN::computeOffsets(), Sundance::NodalDOFMap::computeOffsets(), Sundance::MixedDOFMapHN::computeOffsets(), Sundance::MixedDOFMap::computeOffsets(), Sundance::InhomogeneousNodalDOFMap::computeOffsets(), Sundance::InhomogeneousDOFMapHN::computeOffsets(), Sundance::HomogeneousDOFMap::computeOffsets(), Sundance::PartialElementDOFMap::init(), Sundance::NodalDOFMapHN::init(), Sundance::NodalDOFMap::init(), Sundance::MixedDOFMapHN::initMap(), Sundance::MixedDOFMap::initMap(), Sundance::InhomogeneousDOFMapHN::initMap(), Sundance::HomogeneousDOFMap::initMap(), Sundance::MixedDOFMapHN::shareDOFs(), Sundance::MixedDOFMap::shareDOFs(), Sundance::InhomogeneousDOFMapHN::shareDOFs(), Sundance::HomogeneousDOFMap::shareDOFs(), Sundance::SubmaximalNodalDOFMap::shareRemoteDOFs(), Sundance::PartialElementDOFMap::shareRemoteDOFs(), Sundance::NodalDOFMapHN::shareRemoteDOFs(), Sundance::NodalDOFMap::shareRemoteDOFs(), and Sundance::InhomogeneousNodalDOFMap::shareRemoteDOFs().
Time & DOFMapBase::dofLookupTimer | ( | ) | [static, protected] |
virtual const Array<CellFilter>& Sundance::DOFMapBase::funcDomains | ( | ) | const [pure virtual] |
Return an array of cell filters that gives, for each function ID, the cells that the function lives on.
returnVal.size() == numTotalFunctcions
where returnVal[funcID]
gives a handle to a CellFilterBase
object where the function funcID
lives, where 0 <= funcID < numTotalFunctions
. Implemented in Sundance::InhomogeneousDOFMapHN, Sundance::InhomogeneousEdgeLocalizedDOFMap, Sundance::InhomogeneousNodalDOFMap, Sundance::PartialElementDOFMap, Sundance::SpatiallyHomogeneousDOFMapBase, and Sundance::SubmaximalNodalDOFMap.
void DOFMapBase::getDOFsForCell | ( | int | cellDim, | |
int | cellLID, | |||
int | funcID, | |||
Array< int > & | dofs | |||
) | const [virtual] |
Get the global DOFs for a single function on a single cell.
cellDim | [in] The dimension of the cell | |
cellLID | [in] Local ID (LID) of the cell | |
funcID | [in] Function ID for which DOFs are requested | |
dofs | [out] Global IDs for DOFs of the requested function on the requested cell. |
Definition at line 58 of file SundanceDOFMapBase.cpp.
References dofLookupTimer(), and getDOFsForCellBatch().
Referenced by Sundance::SpatiallyHomogeneousDOFMapBase::print(), Sundance::InhomogeneousNodalDOFMap::print(), Sundance::InhomogeneousEdgeLocalizedDOFMap::print(), and Sundance::HomogeneousDOFMap::print().
virtual RCP<const MapStructure> Sundance::DOFMapBase::getDOFsForCellBatch | ( | int | cellDim, | |
const Array< int > & | cellLIDs, | |||
const Set< int > & | requestedFuncSet, | |||
Array< Array< int > > & | dofs, | |||
Array< int > & | nNodes, | |||
int | verb | |||
) | const [pure virtual] |
Return the global DOFs for a batch of cells for a given set of functions on those cells.
cellDim | [in] The dimension of the cells in the batch of cells | |
cellLIDs | [in] Local IDs (LIDs) for the batch of cells | |
requestedFuncSet | [in] Set of function IDs for which DOFs are requested. Note that this must be equal to the allowed set of requested functions this->allowedFuncsOnCellBatch(cellDim,cellLIDs) . | |
dofs | [out] Global IDs for DOFs of the requested functions on the batch of cells. The size of this array on output is dofs.size()==mapStructure.numBasisChunks() cellLIDs[c] (where 0 <= c < cellLIDs.size() ) for the cell for the basis chunk basisChunk (where 0 <= basisChunk < mapStructure.numBasisChunks() ) are given by dofs[c*nDOFsPerCell[c]+k] k=0...nDOFsPerCell[c]-1 nDOFsPerCell[c] = mapStructure.basis(basisChunk).nNodes( spatialDim, this->mesh()->cellType(cellDim) ) * mapStructure.numFuncs(basisChunk) nDOFsPerCell used above is not actually computed here or returned by this interface. It is only used abstractly to define the dofs array above. | |
nNodes | [out] Array giving the number of coefficients for each type of basis family in mapStructure for each function. The size of this array on return is nNodes.size()==mapStructure.numBasisChunks() and nNodes[b]==mapStructure.basis(b).nNodes(spatialDim,cellType) , for b=0...mapStructure.numBasisChunks()-1 . |
requestedFuncSet.setDifference( this->allowedFuncsOnCellBatch(cellDim,cellLIDs) ).size() == 0
mapStructure
where mapStructure = *returnVal
.
ToDo: Remove the nNodes return argument since this information can be gotten just from the return mapStructure
object. Specifically, nNodes[basisChunk] = mapStructure.basis(basisChunk).nNodes(spatialDim,cellType)
so what is the point in returning this array? Since this is needed for a whole batch of cells, it is cheap to just grab this from the returned mapStructure
object as shown above.
Implemented in Sundance::InhomogeneousDOFMapHN, Sundance::InhomogeneousEdgeLocalizedDOFMap, Sundance::InhomogeneousNodalDOFMap, Sundance::MixedDOFMap, Sundance::MixedDOFMapHN, Sundance::NodalDOFMap, Sundance::NodalDOFMapHN, Sundance::PartialElementDOFMap, and Sundance::SubmaximalNodalDOFMap.
Referenced by getDOFsForCell().
const RCP<Array<int> >& Sundance::DOFMapBase::ghostIndices | ( | ) | const [inline] |
Return an array of the global DOFs for the DOFs that are locally accessed in this process.
Postconditions:
returnVal->size() == ( this->numDOFs() - this->numLocalDOFs() )
returnVal[k] < this->lowsetLocalDOF() && this->lowsetLocalDOF() + this->numLocalDOFs() <= returnVal[k]
, for k=0...(this->numDOFs()-this->numLocalDOFs())-1
.
ToDo: Change the return type to RCP<const Array<int> >
since I doubt that the client is allowed to change this array through this function!
ToDo: Change the name of this function to something like getGhostDOFs()
?
Definition at line 307 of file SundanceDOFMapBase.hpp.
References ghostIndices_.
virtual bool Sundance::DOFMapBase::isHomogeneous | ( | ) | const [inline, virtual] |
Returns true
if the map is homogeneous.
See above defintion for a "Homogeneous" map.
Reimplemented in Sundance::SpatiallyHomogeneousDOFMapBase.
Definition at line 320 of file SundanceDOFMapBase.hpp.
Referenced by Sundance::InhomogeneousNodalDOFMap::getDOFsForCellBatch().
bool Sundance::DOFMapBase::isLocalDOF | ( | int | dof | ) | const [inline] |
Returns true
if the given global DOF is owned in this process.
Definition at line 272 of file SundanceDOFMapBase.hpp.
References lowestLocalDOF_, and numLocalDOFs_.
Referenced by Sundance::SpatiallyHomogeneousDOFMapBase::print(), and Sundance::HomogeneousDOFMap::print().
bool Sundance::DOFMapBase::isRemote | ( | int | cellDim, | |
int | cellLID, | |||
int & | ownerProcID | |||
) | const [inline] |
Return true
if the given cell is really owned by another process and is only ghosted in this process (and optionally return the owning process ID).
cellDim | [in] The dimension of the cell. | |
cellLID | [in] The LID of the cell in this process. See MeshBase for more details, preconditions, etc. | |
ownerProcID | [out] The process rank ID which owns the cell (cellDim,cellLID) . |
MeshBase
ToDo: Change the ownerProcID
argument to int*
and given it a default value of NULL
so that it can be ignored by the client.
ToDo: Consider removing this function and just calling on the mesh object directly.
ToDo: Change name to isRemoteCell()
?
Definition at line 152 of file SundanceDOFMapBase.hpp.
References localProcID_, mesh_, and Sundance::Mesh::ownerProcID().
Referenced by Sundance::InhomogeneousNodalDOFMap::assignNode(), Sundance::PartialElementDOFMap::init(), Sundance::NodalDOFMapHN::init(), Sundance::NodalDOFMap::init(), Sundance::MixedDOFMapHN::initMap(), Sundance::MixedDOFMap::initMap(), Sundance::InhomogeneousDOFMapHN::initMap(), and Sundance::HomogeneousDOFMap::initMap().
int Sundance::DOFMapBase::lowestLocalDOF | ( | ) | const [inline] |
Return the lowest DOF for DOFs owned in this process.
Definition at line 267 of file SundanceDOFMapBase.hpp.
References lowestLocalDOF_.
const Mesh& Sundance::DOFMapBase::mesh | ( | ) | const [inline] |
Definition at line 126 of file SundanceDOFMapBase.hpp.
References mesh_.
Referenced by Sundance::InhomogeneousNodalDOFMap::allowedFuncsOnCellBatch(), Sundance::InhomogeneousEdgeLocalizedDOFMap::allowedFuncsOnCellBatch(), Sundance::InhomogeneousDOFMapHN::allowedFuncsOnCellBatch(), Sundance::InhomogeneousNodalDOFMap::assignNode(), Sundance::MixedDOFMapHN::buildMaximalDofTable(), Sundance::MixedDOFMap::buildMaximalDofTable(), Sundance::InhomogeneousDOFMapHN::buildMaximalDofTable(), Sundance::HomogeneousDOFMap::buildMaximalDofTable(), comm(), Sundance::SubmaximalNodalDOFMap::computeOffsets(), Sundance::PartialElementDOFMap::computeOffsets(), Sundance::NodalDOFMapHN::computeOffsets(), Sundance::NodalDOFMap::computeOffsets(), Sundance::MixedDOFMapHN::computeOffsets(), Sundance::MixedDOFMap::computeOffsets(), Sundance::InhomogeneousNodalDOFMap::computeOffsets(), Sundance::InhomogeneousDOFMapHN::computeOffsets(), Sundance::HomogeneousDOFMap::computeOffsets(), Sundance::PartialElementDOFMap::getDOFsForCellBatch(), Sundance::NodalDOFMapHN::getDOFsForCellBatch(), Sundance::NodalDOFMap::getDOFsForCellBatch(), Sundance::InhomogeneousNodalDOFMap::getDOFsForCellBatch(), Sundance::InhomogeneousEdgeLocalizedDOFMap::getDOFsForCellBatch(), Sundance::InhomogeneousEdgeLocalizedDOFMap::getEdgeLIDs(), Sundance::InhomogeneousNodalDOFMap::getFunctionDofs(), Sundance::NodalDOFMapHN::getPointLIDsForHN(), Sundance::NodalDOFMapHN::getTrafoMatrixForFacet(), Sundance::MixedDOFMapHN::getTrafoMatrixForFacet(), Sundance::InhomogeneousDOFMapHN::getTrafoMatrixForFacet(), Sundance::PartialElementDOFMap::init(), Sundance::NodalDOFMapHN::init(), Sundance::NodalDOFMap::init(), Sundance::MixedDOFMapHN::initMap(), Sundance::MixedDOFMap::initMap(), Sundance::InhomogeneousDOFMapHN::initMap(), Sundance::HomogeneousDOFMap::initMap(), Sundance::InhomogeneousEdgeLocalizedDOFMap::meshDimension(), Sundance::SubmaximalNodalDOFMap::print(), Sundance::SpatiallyHomogeneousDOFMapBase::print(), Sundance::InhomogeneousNodalDOFMap::print(), Sundance::InhomogeneousEdgeLocalizedDOFMap::print(), Sundance::HomogeneousDOFMap::print(), Sundance::MixedDOFMapHN::setDOFs(), Sundance::InhomogeneousDOFMapHN::setDOFs(), Sundance::MixedDOFMapHN::shareDOFs(), Sundance::MixedDOFMap::shareDOFs(), Sundance::InhomogeneousDOFMapHN::shareDOFs(), Sundance::HomogeneousDOFMap::shareDOFs(), Sundance::SubmaximalNodalDOFMap::shareRemoteDOFs(), Sundance::PartialElementDOFMap::shareRemoteDOFs(), Sundance::NodalDOFMapHN::shareRemoteDOFs(), Sundance::NodalDOFMap::shareRemoteDOFs(), and Sundance::InhomogeneousNodalDOFMap::shareRemoteDOFs().
int Sundance::DOFMapBase::numDOFs | ( | ) | const [inline] |
Return the global number of DOFs over all processes.
Postconditions:
returnVal >= this->numLocalDOFs()
Definition at line 288 of file SundanceDOFMapBase.hpp.
References numDOFs_.
int Sundance::DOFMapBase::numLocalDOFs | ( | ) | const [inline] |
Return the number of DOFs owned in this process.
ToDo: Is this the number of owned + ghosted DOFs or is it just owned DOFs?
Definition at line 280 of file SundanceDOFMapBase.hpp.
References numLocalDOFs_.
Referenced by Sundance::MixedDOFMapHN::initMap(), Sundance::MixedDOFMap::initMap(), and Sundance::InhomogeneousDOFMapHN::initMap().
virtual void Sundance::DOFMapBase::print | ( | std::ostream & | os | ) | const [pure virtual] |
Print the DOF map.
ToDo: Replace this with override of Teuchos::Describable::describe().
Implements Playa::Printable.
Implemented in Sundance::HomogeneousDOFMap, Sundance::InhomogeneousDOFMapHN, Sundance::InhomogeneousEdgeLocalizedDOFMap, Sundance::InhomogeneousNodalDOFMap, Sundance::PartialElementDOFMap, Sundance::SpatiallyHomogeneousDOFMapBase, and Sundance::SubmaximalNodalDOFMap.
void Sundance::DOFMapBase::setLowestLocalDOF | ( | int | low | ) | [inline, protected] |
Definition at line 333 of file SundanceDOFMapBase.hpp.
References lowestLocalDOF_.
Referenced by Sundance::SubmaximalNodalDOFMap::computeOffsets(), Sundance::PartialElementDOFMap::computeOffsets(), Sundance::NodalDOFMapHN::computeOffsets(), Sundance::NodalDOFMap::computeOffsets(), Sundance::MixedDOFMapHN::computeOffsets(), Sundance::MixedDOFMap::computeOffsets(), Sundance::InhomogeneousNodalDOFMap::computeOffsets(), Sundance::InhomogeneousDOFMapHN::computeOffsets(), Sundance::HomogeneousDOFMap::computeOffsets(), Sundance::InhomogeneousEdgeLocalizedDOFMap::InhomogeneousEdgeLocalizedDOFMap(), Sundance::MixedDOFMapHN::initMap(), Sundance::MixedDOFMap::initMap(), Sundance::InhomogeneousDOFMapHN::initMap(), and Sundance::HomogeneousDOFMap::initMap().
void Sundance::DOFMapBase::setNumLocalDOFs | ( | int | numDOFs | ) | [inline, protected] |
Definition at line 335 of file SundanceDOFMapBase.hpp.
References numLocalDOFs_.
Referenced by Sundance::SubmaximalNodalDOFMap::computeOffsets(), Sundance::PartialElementDOFMap::computeOffsets(), Sundance::NodalDOFMapHN::computeOffsets(), Sundance::NodalDOFMap::computeOffsets(), Sundance::MixedDOFMapHN::computeOffsets(), Sundance::MixedDOFMap::computeOffsets(), Sundance::InhomogeneousNodalDOFMap::computeOffsets(), Sundance::InhomogeneousDOFMapHN::computeOffsets(), Sundance::HomogeneousDOFMap::computeOffsets(), Sundance::InhomogeneousEdgeLocalizedDOFMap::InhomogeneousEdgeLocalizedDOFMap(), Sundance::MixedDOFMapHN::initMap(), Sundance::MixedDOFMap::initMap(), Sundance::InhomogeneousDOFMapHN::initMap(), and Sundance::HomogeneousDOFMap::initMap().
void Sundance::DOFMapBase::setTotalNumDOFs | ( | int | numDOFs | ) | [inline, protected] |
Definition at line 337 of file SundanceDOFMapBase.hpp.
References numDOFs_.
Referenced by Sundance::SubmaximalNodalDOFMap::computeOffsets(), Sundance::PartialElementDOFMap::computeOffsets(), Sundance::NodalDOFMapHN::computeOffsets(), Sundance::NodalDOFMap::computeOffsets(), Sundance::MixedDOFMapHN::computeOffsets(), Sundance::MixedDOFMap::computeOffsets(), Sundance::InhomogeneousNodalDOFMap::computeOffsets(), Sundance::InhomogeneousDOFMapHN::computeOffsets(), Sundance::HomogeneousDOFMap::computeOffsets(), Sundance::InhomogeneousEdgeLocalizedDOFMap::InhomogeneousEdgeLocalizedDOFMap(), Sundance::MixedDOFMapHN::initMap(), Sundance::MixedDOFMap::initMap(), Sundance::InhomogeneousDOFMapHN::initMap(), and Sundance::HomogeneousDOFMap::initMap().
int Sundance::DOFMapBase::setupVerb | ( | ) | const [inline] |
Definition at line 330 of file SundanceDOFMapBase.hpp.
References setupVerb_.
Referenced by Sundance::MixedDOFMapHN::allocate(), Sundance::MixedDOFMap::allocate(), Sundance::InhomogeneousDOFMapHN::allocate(), Sundance::HomogeneousDOFMap::allocate(), Sundance::InhomogeneousDOFMapHN::allowedFuncsOnCellBatch(), Sundance::MixedDOFMapHN::buildMaximalDofTable(), Sundance::MixedDOFMap::buildMaximalDofTable(), Sundance::InhomogeneousDOFMapHN::buildMaximalDofTable(), Sundance::HomogeneousDOFMap::buildMaximalDofTable(), Sundance::NodalDOFMapHN::computeOffsets(), Sundance::MixedDOFMapHN::computeOffsets(), Sundance::MixedDOFMap::computeOffsets(), Sundance::InhomogeneousDOFMapHN::computeOffsets(), Sundance::HomogeneousDOFMap::computeOffsets(), Sundance::MixedDOFMapHN::getDOFsForHNCell(), Sundance::InhomogeneousDOFMapHN::getDOFsForHNCell(), Sundance::NodalDOFMapHN::getPointLIDsForHN(), Sundance::MixedDOFMapHN::getTrafoMatrixForCell(), Sundance::InhomogeneousDOFMapHN::getTrafoMatrixForCell(), Sundance::NodalDOFMapHN::getTrafoMatrixForFacet(), Sundance::MixedDOFMapHN::getTrafoMatrixForFacet(), Sundance::InhomogeneousDOFMapHN::getTrafoMatrixForFacet(), Sundance::PartialElementDOFMap::init(), Sundance::NodalDOFMapHN::init(), Sundance::NodalDOFMap::init(), Sundance::MixedDOFMapHN::initMap(), Sundance::MixedDOFMap::initMap(), Sundance::InhomogeneousDOFMapHN::initMap(), Sundance::HomogeneousDOFMap::initMap(), Sundance::MixedDOFMapHN::setDOFs(), Sundance::MixedDOFMap::setDOFs(), Sundance::InhomogeneousDOFMapHN::setDOFs(), Sundance::HomogeneousDOFMap::setDOFs(), Sundance::MixedDOFMapHN::shareDOFs(), Sundance::MixedDOFMap::shareDOFs(), Sundance::InhomogeneousDOFMapHN::shareDOFs(), Sundance::HomogeneousDOFMap::shareDOFs(), Sundance::SubmaximalNodalDOFMap::shareRemoteDOFs(), Sundance::PartialElementDOFMap::shareRemoteDOFs(), Sundance::NodalDOFMapHN::shareRemoteDOFs(), and Sundance::NodalDOFMap::shareRemoteDOFs().
RCP<Array<int> > Sundance::DOFMapBase::ghostIndices_ [private] |
Definition at line 363 of file SundanceDOFMapBase.hpp.
Referenced by addGhostIndex(), and ghostIndices().
int Sundance::DOFMapBase::localProcID_ [private] |
int Sundance::DOFMapBase::lowestLocalDOF_ [private] |
Definition at line 357 of file SundanceDOFMapBase.hpp.
Referenced by isLocalDOF(), lowestLocalDOF(), and setLowestLocalDOF().
Mesh Sundance::DOFMapBase::mesh_ [private] |
Definition at line 355 of file SundanceDOFMapBase.hpp.
Referenced by cellDim(), isRemote(), and mesh().
int Sundance::DOFMapBase::numDOFs_ [private] |
Definition at line 361 of file SundanceDOFMapBase.hpp.
Referenced by numDOFs(), and setTotalNumDOFs().
int Sundance::DOFMapBase::numLocalDOFs_ [private] |
Definition at line 359 of file SundanceDOFMapBase.hpp.
Referenced by isLocalDOF(), numLocalDOFs(), and setNumLocalDOFs().
int Sundance::DOFMapBase::setupVerb_ [private] |
