Sundance::CellFilterBase Class Reference
Base class for CellFilter objects. More...
Public Member Functions | |
| CellFilterBase () | |
| Empty ctor. | |
| virtual | ~CellFilterBase () |
| virtual dtor | |
| CellSet | getCells (const Mesh &mesh) const |
| Find the cells passing this filter on the given mesh. | |
| virtual int | dimension (const Mesh &mesh) const =0 |
| Return the dimension of the cells that will be identified by this filter when acting on the given mesh. | |
| void | registerSubset (const CellFilter &sub) const |
| void | registerLabeledSubset (int label, const CellFilter &sub) const |
| void | registerDisjoint (const CellFilter &sub) const |
| const Set< CellFilter > & | knownSubsets () const |
| const Set< CellFilter > & | knownDisjoints () const |
| virtual std::string | toString () const |
| virtual std::string | description () const |
| Print to a stream. | |
| void | setName (const std::string &name) |
| void | flushCache () const |
| empties the cache of the filter | |
Protected Member Functions | |
| virtual CellSet | internalGetCells (const Mesh &mesh) const =0 |
Private Attributes | |
| Sundance::Map< int, CellSet > | cellSetCache_ |
| cache of previously computed cell sets | |
| std::string | name_ |
Detailed Description
Base class for CellFilter objects.
Notes for subclass implementors
Derived classes must implement the methods
- internalGetCells() -- returns the set of cells that pass through this filter
- dimension() -- returns the dimension of the cells that will pass through this filter
- toXML() -- writes an XML description of the filter
- lessThan() -- compares to another cell filter. Used to store cell filters in STL containers.
- typeName() -- returns the name of the subclass. Used in ordering.
Definition at line 64 of file SundanceCellFilterBase.hpp.
Constructor & Destructor Documentation
| CellFilterBase::CellFilterBase | ( | ) |
| CellFilterBase::~CellFilterBase | ( | ) | [virtual] |
Member Function Documentation
| virtual std::string Sundance::CellFilterBase::description | ( | ) | const [inline, virtual] |
Print to a stream.
Reimplemented in Sundance::DimensionalCellFilter, Sundance::LabeledSubsetCellFilter, Sundance::MaximalCellFilter, Sundance::SideCellFilter, and Sundance::SubsetCellFilter.
Definition at line 100 of file SundanceCellFilterBase.hpp.
References toString().
| virtual int Sundance::CellFilterBase::dimension | ( | const Mesh & | mesh | ) | const [pure virtual] |
Return the dimension of the cells that will be identified by this filter when acting on the given mesh.
Implemented in Sundance::BinaryCellFilter, Sundance::DimensionalCellFilter, Sundance::MaximalCellFilter, Sundance::SideCellFilter, and Sundance::SubsetCellFilter.
Referenced by Sundance::CellFilter::dimension().
| void CellFilterBase::flushCache | ( | ) | const |
empties the cache of the filter
Definition at line 61 of file SundanceCellFilterBase.cpp.
References cellSetCache_.
Find the cells passing this filter on the given mesh.
This method will cache the cell sets it computes for each mesh
Definition at line 51 of file SundanceCellFilterBase.cpp.
References cellSetCache_, Sundance::Map< Key, Value, Compare >::containsKey(), Sundance::Map< Key, Value, Compare >::get(), Sundance::Mesh::id(), internalGetCells(), and Sundance::Map< Key, Value, Compare >::put().
Referenced by Sundance::CellFilter::getCells().
| virtual CellSet Sundance::CellFilterBase::internalGetCells | ( | const Mesh & | mesh | ) | const [protected, pure virtual] |
Implemented in Sundance::BinaryCellFilter, Sundance::DimensionalCellFilter, Sundance::LabeledSubsetCellFilter, Sundance::MaximalCellFilter, Sundance::SideCellFilter, and Sundance::SubsetCellFilter.
Referenced by getCells().
| const Set<CellFilter>& Sundance::CellFilterBase::knownDisjoints | ( | ) | const |
| const Set<CellFilter>& Sundance::CellFilterBase::knownSubsets | ( | ) | const |
| void Sundance::CellFilterBase::registerDisjoint | ( | const CellFilter & | sub | ) | const |
| void Sundance::CellFilterBase::registerLabeledSubset | ( | int | label, | |
| const CellFilter & | sub | |||
| ) | const |
| void Sundance::CellFilterBase::registerSubset | ( | const CellFilter & | sub | ) | const |
| void Sundance::CellFilterBase::setName | ( | const std::string & | name | ) | [inline] |
Definition at line 104 of file SundanceCellFilterBase.hpp.
References name_.
Referenced by Sundance::BinaryCellFilter::BinaryCellFilter(), Sundance::BoundaryCellFilter::BoundaryCellFilter(), Sundance::DimensionalCellFilter::DimensionalCellFilter(), Sundance::MaximalCellFilter::MaximalCellFilter(), Sundance::CellFilter::setName(), Sundance::SideCellFilter::SideCellFilter(), and Sundance::SubsetCellFilter::SubsetCellFilter().
| virtual std::string Sundance::CellFilterBase::toString | ( | ) | const [inline, virtual] |
Definition at line 97 of file SundanceCellFilterBase.hpp.
References name_.
Referenced by Sundance::DimensionalCellFilter::description(), description(), Sundance::BinaryCellFilter::internalGetCells(), and Sundance::CellFilter::toString().
Member Data Documentation
Sundance::Map<int, CellSet> Sundance::CellFilterBase::cellSetCache_ [mutable, private] |
cache of previously computed cell sets
Definition at line 116 of file SundanceCellFilterBase.hpp.
Referenced by flushCache(), and getCells().
std::string Sundance::CellFilterBase::name_ [private] |
