Public Member Functions | |
BamgMeshReader (const std::string &filename, const MeshType &meshType, const bool bbAttr, int verbosity=0, const MPIComm &comm=MPIComm::world()) | |
BamgMeshReader (const ParameterList ¶ms) | |
virtual | ~BamgMeshReader () |
virtual Mesh | fillMesh () const |
virtual std::string | description () const |
virtual RCP< MeshSourceBase > | getRcp () |
Private Member Functions | |
void | readParallelInfo (Array< int > &ptGID, Array< int > &ptOwner, Array< int > &elemGID, Array< int > &elemOwner) const |
Mesh | readNodes (Array< int > &ptGID, Array< int > &ptOwner) const |
void | readElems (Mesh &mesh, const Array< int > &nodeGID, Array< int > &elemGID, Array< int > &elemOwner) const |
Mesh | readMesh (Array< int > &ptGID, Array< int > &ptOwner) const |
Private Attributes | |
std::string | nodeFilename_ |
std::string | elemFilename_ |
std::string | parFilename_ |
std::string | meshFilename_ |
std::string | bbFilename_ |
int | bbAttr_ |
!!The description below is for TriangleMeshReader & needs modification!!
This format is documented at the Triangle homepage. This reader expects to find node information in .node
files and element information in .ele
files. The filename
constructor argument is the stem of the filenames, and so that a reader constructed with filename joe
will look for node and element data in joe.node
and joe.ele
respectively. Node and element attributes are read if present, and can be accessed with the getAttributes()
method of MeshSource.
We have extended the Triangle format to deal with distributed meshes. A TriangleMeshReader is constructed with an MPIComm object, and if that communicator has more than one processor the mesh is assumed to be split into files, one for each processor. Data on mesh "joe" for the nnn-th processor will be found in the files
joe.node.
nnn joe.ele.
nnn joe.par.
nnn .node.
nnn and .ele.
nnn files contain the node and element data for the part of the mesh seen by the nnn-th processor. The node and element numberings given in those two files are local indexes. The .par.
nnn contains node and element ownership information for the part of the mesh seen by the nnn-th processor.
A .par
file is formatted as follows:
rank numProcs
numPoints
ptLID ptGID ptOwnerRank
numElems
elemLID elemGID elemOwnerRank
Definition at line 95 of file SundanceBamgMeshReader.hpp.
BamgMeshReader::BamgMeshReader | ( | const std::string & | filename, | |
const MeshType & | meshType, | |||
const bool | bbAttr, | |||
int | verbosity = 0 , |
|||
const MPIComm & | comm = MPIComm::world() | |||
) |
Definition at line 10 of file SundanceBamgMeshReader.cpp.
References bbFilename_, elemFilename_, meshFilename_, Sundance::MeshSourceBase::myRank(), nodeFilename_, Sundance::MeshSourceBase::nProc(), parFilename_, SUNDANCE_OUT, Sundance::toString(), and Playa::ObjectWithVerbosity::verb().
BamgMeshReader::BamgMeshReader | ( | const ParameterList & | params | ) |
Construct from a ParameterList
Definition at line 52 of file SundanceBamgMeshReader.cpp.
References bbFilename_, elemFilename_, meshFilename_, Sundance::MeshSourceBase::myRank(), nodeFilename_, Sundance::MeshSourceBase::nProc(), parFilename_, SUNDANCE_OUT, Sundance::toString(), and Playa::ObjectWithVerbosity::verb().
virtual Sundance::BamgMeshReader::~BamgMeshReader | ( | ) | [inline, virtual] |
virtual dtor
Definition at line 107 of file SundanceBamgMeshReader.hpp.
virtual std::string Sundance::BamgMeshReader::description | ( | ) | const [inline, virtual] |
Print a short descriptive std::string
Reimplemented from Sundance::MeshSourceBase.
Definition at line 114 of file SundanceBamgMeshReader.hpp.
References Sundance::MeshReaderBase::filename().
Mesh BamgMeshReader::fillMesh | ( | ) | const [virtual] |
Create a mesh
Implements Sundance::MeshSourceBase.
Definition at line 89 of file SundanceBamgMeshReader.cpp.
References readMesh(), and readParallelInfo().
virtual RCP<MeshSourceBase> Sundance::BamgMeshReader::getRcp | ( | ) | [inline, virtual] |
Method for reading a .bb file Return a ref count pointer to self
Implements Playa::Handleable< MeshSourceBase >.
Definition at line 122 of file SundanceBamgMeshReader.hpp.
void Sundance::BamgMeshReader::readElems | ( | Mesh & | mesh, | |
const Array< int > & | nodeGID, | |||
Array< int > & | elemGID, | |||
Array< int > & | elemOwner | |||
) | const [private] |
Mesh BamgMeshReader::readMesh | ( | Array< int > & | ptGID, | |
Array< int > & | ptOwner | |||
) | const [private] |
add method that reads both nodes and elements from a single file
Definition at line 240 of file SundanceBamgMeshReader.cpp.
References Sundance::Mesh::addElement(), Sundance::Mesh::addVertex(), Sundance::MeshReaderBase::atof(), Sundance::MeshReaderBase::atoi(), bbAttr_, bbFilename_, Sundance::MeshSourceBase::createMesh(), Sundance::dimension(), Sundance::MeshSourceBase::elemAttributes(), meshFilename_, Sundance::MeshSourceBase::nodeAttributes(), Sundance::MeshReaderBase::openFile(), Sundance::Mesh::spatialDim(), SUNDANCE_OUT, and Playa::ObjectWithVerbosity::verb().
Referenced by fillMesh().
Mesh Sundance::BamgMeshReader::readNodes | ( | Array< int > & | ptGID, | |
Array< int > & | ptOwner | |||
) | const [private] |
void BamgMeshReader::readParallelInfo | ( | Array< int > & | ptGID, | |
Array< int > & | ptOwner, | |||
Array< int > & | elemGID, | |||
Array< int > & | elemOwner | |||
) | const [private] |
Definition at line 111 of file SundanceBamgMeshReader.cpp.
References Sundance::MeshReaderBase::atoi(), Sundance::MeshReaderBase::getNextLine(), Sundance::MeshSourceBase::myRank(), Sundance::MeshSourceBase::nProc(), Sundance::MeshReaderBase::openFile(), parFilename_, SUNDANCE_OUT, SUNDANCE_TRACE, and Playa::ObjectWithVerbosity::verb().
Referenced by fillMesh().
int Sundance::BamgMeshReader::bbAttr_ [private] |
number of bb Attributes
Definition at line 162 of file SundanceBamgMeshReader.hpp.
Referenced by readMesh().
std::string Sundance::BamgMeshReader::bbFilename_ [private] |
add a bb filename
Definition at line 159 of file SundanceBamgMeshReader.hpp.
Referenced by BamgMeshReader(), and readMesh().
std::string Sundance::BamgMeshReader::elemFilename_ [private] |
std::string Sundance::BamgMeshReader::meshFilename_ [private] |
add a mesh filename
Definition at line 156 of file SundanceBamgMeshReader.hpp.
Referenced by BamgMeshReader(), and readMesh().
std::string Sundance::BamgMeshReader::nodeFilename_ [private] |
add method for reading a .bb file
Definition at line 147 of file SundanceBamgMeshReader.hpp.
Referenced by BamgMeshReader().
std::string Sundance::BamgMeshReader::parFilename_ [private] |
Definition at line 153 of file SundanceBamgMeshReader.hpp.
Referenced by BamgMeshReader(), and readParallelInfo().
